| Material | Tin-Plated Copper |
| Category | terminal |
| Applications | cable |
| Production process | cold |
| Type | SNB3.5-4 |
| Compatible with Cable Size | 2.5-4mm²(A.W.G 14-12) |
| Max. Current | 37A |
| Quantity | 100pcs |
[Crimp Securely] - If you solder all crimps, our spade wire connectors crimp securely, take soldering iron heat very quickly, and 60/40 solder will suck into the crimp instantly and quite nicely; a nice concave taper to the fork.
[Fit Cable Size] - Great spade wire connectors, they're not too large so they're easy to use with basic primary wire, suits cable/ wire size : 12-10AWG 4.0-6.0 sq.mm; Bolt Mouth Size (suits screw DIA) : 4.3mm / 0.169 Inch.
[High Quality] - The thickness complies with international standard, so our insulated fork spade wire connector has good electrical conductivity and also has a insulated shell which make it better performance.
[Easy Use] - With these fork spade wire connectors, a drop or two of flux and apply the heat, then a touch of tin and your done, beautiful solder joints you get!
Feature
1.Compatible with use in machinery, electricity, railways, shipbuilding, aviation, household appliances, computers or other automation equipment.
2.With a full port design, it is ideal for solid or stranded wires that are difficult to crimp.
3.Each fork terminal is rolled up and the seams are butted. The seam is not open under normal stress or wire conditions.
|
Product type |
Fork Spade Bare Terminals |
|
Color |
/ |
|
Item NO. |
SNB1.25, SNB2, SNB3.5, SNB5.5, SNB8 |
|
Cable size |
AWG22-16,AWG16-14,AWG14-12,AWG12-10 |
|
Max current |
19A,27A,37A,48A |
|
Material |
Copper alloy, Copper |
